APPA
APPA
OVERVIEW
APPA is a quadcopter with four motors and a range of 500m–1km. It has a thrust of 1.25 kg per motor and a payload capacity of 400 grams. It can perform flights lasting up to 10 minutes. Our vehicle is capable of carrying out its missions fully autonomously.
TECHNICAL SPECIFICATIONS
- TAKEOFF WEIGHT 2.08 kg
- CRUISE SPEED 14 m/s
- FLIGHT TIME 8.2 dk
- ALTITUDE RANGE 5-30 m
- BATTERY 3400 mAh
- TAKEOFF/LANDING AUTONOMOUS
HARDWARE SPECIFICATIONS
- FLIGHT COMPUTER PIXHAWK CUBE BLACK
- MISSION COMPUTER NVIDIA JETSON NANO 4GB
- GPS PIXHAWK HERE2 GPS
- CAMERA PI KAMERA v2
- MOTOR EMAX XA2212 980kV
- BATTERY LEOPARD 3S 3400 mAh LİPO
- RADIO CONTROLLER FLYSKY - I6X 2.4 GHz
TECHNICAL DRAWINGS AND 3D MODELS
